NVIDIA GeForce RTX 3070 Review: Breakout Performance At $499

Article Index

NVIDIA GeForce RTX 3070: Compute, Rendering, And Synthetic Tests

How We Configured Our Test Systems: We tested the graphics cards represented in this article on an ASUS Prime X299 Deluxe motherboard powered by a Core i9-10980XE 18-core / 36-thread processor and 32GB of HyperX DDR4 RAM clocked at 2,933MHz. The first thing we did when configuring the test system was enter the UEFI and set all values to their "high performance" defaults, then we disabled any integrated peripherals that wouldn't be put to use. The memory's clock was dialed in to its optimal performance settings using its XMP profile and the solid state drive was then formatted and Windows 10 Professional x64 was installed and fully updated. When the Windows installation was complete, we installed all of the drivers, games, applications and benchmark tools necessary to complete our tests.

geforce rtx 3070 open

HotHardware's Test System
Intel Core i9 Powered
Hardware Used:
Intel Core i9-10980XE
(3GHz - 4.4GHz, 18-Core)

ASUS X299 Prime
(Intel X299 Chipset)

32GB Corsair DDR4-2933
Samsung SSD 970 EVO
Integrated Audio
Integrated Network

NVIDIA GeForce RTX 3070 FE
NVIDIA GeForce RTX 3080 FE
NVIDIA Titan RTX
NVIDIA GeForce RTX 2080 Ti FE
NVIDIA GeForce RTX 2080 Super
NVIDIA GeForce RTX 2070 Super
AMD Radeon RX 5700 XT
AMD Radeon RX 5600 XT

Relevant Software:
Windows 10 Pro x64 (v2004)
AMD Radeon Software v20.8.3
NVIDIA GeForce Drivers v456.16/.96

Benchmarks Used:
IndigoBench v4
LuxMark v4_alpha0
SiSoft SANDRA 2020
VRMark
3DMark (Time Spy, Fire Strike, Port Royal)
Unigine Superposition
Crytek Neon Noir
Metro Exodus
Red Dead Redemption 2
Gears Tactics
Wolfenstein: Youngblood
FarCry: New Dawn

SiSoft SANDRA 2020
Cryptography And Image Processing OpenCL Performance Tests
SANDRA's GPGPU Image Processing benchmark runs through an array of filters on its reference data and offers up an aggregate score, derived from a number of individual results. CUDA and OpenCL code paths are available in these tests, but we used OpenCL on all cards to keep the playing field level. Previously, using the CUDA path with NVIDIA GPUs resulted in better performance, but OpenCL actually outperforms CUDA in these tests now...

image processing 3070

The GeForce RTX 3070 FE absolutely crushes all of the previous-generation GPUs in SANDRA's image processing benchmark and trails only the higher-end, pricier GeForce RTX 3080.

LuxMark v4.0_alpha0
OpenCL Benchmark

LuxMark is a cross-platform,
OpenCL-accelerated 3D rendering benchmark. It's a tool based on the open source LuxRender physically-based spectral rendering engine, which accurately models the transportation of light and supports high dynamic range. LuxRender features a number of material types to allow rendering of photo-realistic and artistic scenes. LuxRender is free software, licensed under the GPL, that offers plugins for packages like Blender, Maya, Cinema 4D and 3DS Max.

luxmark 3070

The same thing we saw with image processing rings true in Luxmark as well. Here, the GeForce RTX 3070 FE smokes every previous-gen card by a wide margin, and trails only the RTX 3080.

IndigoBench
GPU Rendering Performance
IndigoBench is based on Indigo 4's advanced rendering engine and offers both CPU and GPU rendering modes for its two built-in models. The standalone benchmark is available for Windows, MacOS, and Linux and outputs results in M/Samples per second.

indigo bench 3070

The tables turn slightly with IndigoBench. Here, the GeForce RTX 2080 Ti is able to overtake the GeForce RTX 3070 FE by a few percentage points, but the 3070 finishes well ahead of the RTX 2080 Super and everything below it.

Unigine Superposition
Pseudo-DirectX / OpenGL Gaming
Superposition is a relatively new benchmark from Unigine, powered by the UNIGINE 2 Engine. It offers an array of benchmark modes, targeting gaming workloads as well as VR, with both DirectX and OpenGL code paths. There is an extreme hardware stability test built-in as well. Unigine Superposition uses the developer’s unique SSRTGI (Screen-Space Ray-Traced Global Illumination) dynamic lighting technology, along with high quality textures and models, to produce some stunning visuals. We ran Superposition in two modes using the DirectX code path – 1080p Extreme and VR Future -- to compare the performance of all of the graphics cards featured here.

unigine superposition
Unigine Superposition

unigine 1 3070


unigine 2 3070

Unigine Superposition's 1080P Extreme test put the GeForce RTX 3070 FE every so slightly ahead of the GeForce RTX 2080 Ti, but we're talking about a miniscule delta here. Versus the similarly-priced RTX 2070 Super, the new GeForce RTX 3070 is simply in another league altogether.

unigine 3a 3070


unigine 4a 3070


unigine 5a 3070

Superposition's VR Future test has the GeForce RTX 3070 FE landing smack dab in between the GeForce RTX 2080 Super and RTX 2080 Ti.
UL VRMark
Testing Rift And Vive Readiness
UL's VRMark is designed to test a PC’s readiness for the HTC Vive and Oculus Rift virtual reality headsets. The benchmark does not, however, require that one of the headsets is attached to the PC to run and it uses an in-house graphics engine and content to ensure comparable results between different platforms. We ran the "Blue Room" VRMark test at defaults settings here, which is currently the most taxing test offered by the tool.

vr mark thumb
Futuremark VRMark

vrmark details
GeForce RTX 3070 VRMark Details

vrmark 1 3070


vrmark 2 3070

In VR Mark, the GeForce RTX 2080 Ti jumps out to a sizable lead over the GeForce RTX 3070 FE, but the 3070 has no trouble dispatching the RTX 2080 Super.

UL 3DMark Time Spy
Direct X 12 Performance

3DMark Time Spy is a synthetic DirectX benchmark test from Futuremark. It features a DirectX 12 engine built from the ground up to support bleeding-edge features like asynchronous compute, explicit multi-adapter, and multithreading. Time Spy is designed to test the DirectX 12performance of the latest graphics cards using a variety of techniques and varied visual sequences. This benchmark was developed with input from AMD, Intel, Microsoft, NVIDIA, and the other members of the Futuremark Benchmark Development Program, to showcase the performance and visual potential of graphics cards and other system resources driven by close-to-the-metal, low-overhead APIs.
time spy
3DMark Time Spy
time spy details
GeForce RTX 3070 Time Spy Details

time spy 2 3070


time spy 1 3070


In the DX12-based 3DMark Tme Spy benchmark, the GeForce RTX 3070 FE just misses the mark set by the GeForce RTX 2080 Ti. It finishes well ahead of the RTX 2070 and 2080 Super, however, and leaves AMD's Radeon RX 5700 XT in the dust.

UL 3DMark Fire Strike
Synthetic DirectX Gaming
3DMark Fire Strike has multiple benchmark modes: Normal mode runs at 1920x1080, Extreme mode targets 2560x1440, and Ultra mode runs at a 4K resolution. GPU target frame buffer utilization for normal mode is 1GB and the benchmark uses tessellation, ambient occlusion, volume illumination, and a medium-quality depth of field filter. The more taxing Extreme mode targets 1.5GB of frame buffer memory and increases detail levels across the board. Ultra mode is explicitly designed for high-end and CrossFire / SLI systems and cranks up the quality even further. GT 1 focuses on geometry and illumination, with over 100 shadow casting spot lights, 140 non-shadow casting point lights, and 3.9 million vertices calculated for tessellation per frame. GT2 emphasizes particles and GPU simulations.

3d mark fire strike
3DMark Fire Strike
fire strike details
GeForce RTX 3070 Fire Strike Ultra Details

firestrike 1 3070


firestrike 2 3070

Our results in the DX11-based Fire Strike benchmark show the GeForce RTX 3070 FE outpacing the GeForce RTX 2080 Ti in the Combined Test and Game Test 2, which give it enough of an edge to pull out a higher overall score within striking distance of the Titan RTX.

UL 3DMark Port Royal
DXR Ray Tracing Benchmark

Port Royal was released earlier this year as an update to UL’s popular 3DMark suite. It is designed to test real-time ray tracing performance of graphics cards that support Microsoft DirectX Raytracing, or DXR. Although DXR is technically compatible with all DX12-class GPUs, the graphics card must have drivers that enable DXR, and NVIDIA is the only company to have done so at this point, hence the lack of Radeons in the chart.

3mark port royal dxr
3DMark Port Royal
ports royal details
GeForce RTX 3070 Port Royal Details

port royal 2 3070


port royal 1 3070

The GeForce RTX 3070 FE drops in a few percentage points behind the 2080 Ti in the Port Royal Ray Tracing benchmark, though it's nearly 34% ahead of the GeForce RTX 2070 Super.
